Linear Light

  • Range :
    Linear Light
  • Code :
    JQL-GRY-LRLR012W
  • Description :
    • Luminous Flux 840 lm @4000K
    • Power Consumption 12W
    • Beam Angle (50%Imax) 150°
    • Color Temperature 2700K / 3000K / 4000K / 5000K / 5700K / 6500K / RGB / RGBW
    • LED Brand CREE/ NICHIA/ OSRAM/ LUMILEDS
    • Input Voltage DC24V
    • Protection Class IEC III
    • Control DMX / RDM / Remote / DALI / ON-OFF
    • Power Factor ≥0.95
    • Pixel 8
    • Finish Powder coating / Anode oxidation
    • Housing Extruded aluminum 6063
    • Diffuser High strength optical PMMA
    • Dimensions W1000 / W25xH50.5 / W28xH44.5mm
    • IP Rating IP65 / IP66 / IP67 / IP68
    • IK Rating IK06 / IK07
    • Mounting Adjustable bracket
    • Operating Temperature -35°C ~ 60°C (-31°F ~ 140°F)
    • Storage Temperature -40°C ~ 70°C (-40°F ~ 158°F)
    • THD <10%
    • Lifespan >50,000Hrs (Ta=35°C@L70)
    • Certificate BIS / CE / RoHS
