Wallwasher 72W

  • Range :
    Wall Washer
  • Code :
    JQL-GRY-WWL072W
  • Description :
    • Luminous Flux 5184 lm @4000K
    • Power Consumption 72W
    • Beam Angle (50%Imax) 10° / 15° / 30° / 45° / 60° / 80° / 12*20° / 12*45°
    • Color Temperature 2700K / 3000K / 4000K / 5000K / 5700K / 6500K / RGB / RGBW
    • LED Brand CREE/ NICHIA/ OSRAM/ LUMILEDS
    • Input Voltage AC100-240V 50/60Hz
    • Protection Class IEC I
    • Control DMX / RDM / DALI / Remote / ON-OFF
    • Dimensions W1000 / W60 / W42xH56
    • Finish Powder coating
    • Housing Extruded aluminum 6063
    • Cover Toughened glass
    • IP Rating IP66 / IP67
    • IK Rating IK08
    • Mounting Adjustable bracket
    • Operating Temperature -35°C ~ 60°C (-31°F ~ 140°F)
    • Storage Temperature -40°C ~ 70°C (-40°F ~ 158°F)
    • Lifespan >50,000Hrs (Ta=35°C@L70)
    • Certificate BIS / CE / RoHS
